Wilwood Superlite 6R 12.88" Front Disc Brakes, 66-75 Ford Bronco SKU: 140-13304N

Wilwood Superlite 6R 12.88" Front Disc Brakes, 66-75 Ford Bronco

Wilwood Superlite 6R 12.88" Front Disc Brakes 66-75 Bronco

Free Shipping!

Product Overview:

The unsurpassed braking capacity of the Wilwood Forged Narrow Superlite 6R six-piston caliper serves as the base of this 12.88" rotor kit for 1966-75 Ford Broncos.

Requires minimum 17 inch wheel diameter. Consult the Wheel Clearance Diagram in additional images to confirm fitment before purchasing.

FREE SHIPPING to anywhere in the 48 contiguous states. The shipping charge for this item will have already been deducted from the shipping charge in checkout. Customers outside the 48 states will be contacted with shipping charges for approval prior to shipping.
NOTE: For non-defective returns, original shipping costs incurred by Wild Horses will be deducted from any refunds. Customers responsible for any return shipping costs incurred.

Full description

The unsurpassed braking capacity of the Wilwood Forged Narrow Superlite 6R six-piston caliper serves as the base of this 12.88" rotor kit for 1966-75 Ford Broncos.

Requires minimum 17 inch wheel diameter. Consult the Wheel Clearance Diagram in additional images to confirm fitment before purchasing.

This Wilwood Forged Narrow Superlite 6R Front Disc Brake Kit is designed specifically for early Ford Broncos. This kit features the exceptional braking performance of Wilwood's Forged Narrow Superlite 6R six-piston caliper as the foundation, paired with a substantial 12.88" brake rotor designed specifically for 1966-1975 Ford Broncos. Engineered with a focus on application-specific design, the SL6 kits ensure a simplified installation process and seamless compatibility with OE master cylinder output and ABS functions, where applicable.

These big brake kits not only enhance braking capacity but also complement the overall aesthetic of your early Bronco when combined with wheel, tire, and suspension upgrades.

Key Specifications:

Fits 1966-1975 Ford Bronco
Pistons: 6
Rotor Diameter: 12.88"
Caliper Mount: Radial
Spindle Type: Factory Drum Spindle (not included)
Wheel Diameter: 17" minimum
Flange: Axle Offset: +.00

Note: The Wilwood Line Kit 220-13319 is included in this comprehensive kit, ensuring a well-rounded solution for your braking needs.

California residents: Proposition 65 Warning

Q&A

Please Sign In if you have a question or want to post an answer.

NEED HELP? Talk to a BRONCO expert today! (209) 400-7200

PRODUCT REVIEWS

Leland R Nunez

Reviewed 08/15/2019

I used to have a Busted up vacuum booster with an old chevy Disc brake conversion up front, and the stock skinny drums in the rear. Then add some 35 inch tires and there was nothing more scary than than tossing the keys to my wife and sitting shotgun! After i installed the 17" kit, (love 17"rims on 35's) and HydroBoost brake assist, my bronco now feels more like a sports car! Now I can ride shotgun without having a small heart attack every time i see brake lights in front of me.
