Super 9 Ford 9-inch Housing, Large Bearing, 66-77 Bronco SKU: 8689NETW
Super 9 Ford 9-inch Housing, Large Bearing, 66-77 Bronco
Super 9 Ford 9-inch Housing Large Bearing 66-77 Bronco
Product Overview:
The WH 'Super 9' Ford 9-inch Rear Axle Housing enhances the original early Bronco design by offering a stronger, welded center section and thick DOM tubes, which significantly improve the axle's support and strength. This premium early Bronco rear axle housing also features large bearing billet ends, pre-welded leaf spring mounts, and a pre-drilled breather hole for easy installation and increased durability. This product provides an affordable and durable solution for upgrading the rear axle of your 66-77 Ford Bronco.
- 23" wide, fully welded center section
- 3" x .250" wall DOM tubing
- Large bearing, billet axle housing ends
Full description
The WH 'Super 9' Ford 9-inch Rear Axle Housing enhances the original early Bronco design by offering a stronger, welded center section and thick DOM tubes, which significantly improve the axle's support and strength.
This premium early Bronco rear axle housing also features large bearing billet ends, pre-welded leaf spring mounts, and a pre-drilled breather hole for easy installation and increased durability. This product
provides an affordable and durable solution for upgrading the rear axle of your 66-77 Ford Bronco.
- 23" wide, fully welded center section
- 3" x .250" wall DOM tubing
- Large bearing, billet axle housing ends
Early Bronco Ford 9" Rear Axle Housing
Heavy Duty, Fits 3-1/8" Large Bearing
Most of the original early Bronco Ford 9-inch rear axle housings are weak "banjo" type housings. They had a round center section with minimal support for the axle tubes. In 76-77 Ford Broncos, the rear axle housing was a little better with a larger, wider center section. This provided added support for the axle tubes. The WH Super 9 Ford 9-inch Rear Axle Housing offers a superior housing at an affordable price with the following features.
- 23" wide Rear Axle Housing Center Section
- Welded for additional strength and support for the axle tubes.
- Welded for additional strength and support for the axle tubes.
- 3" x .250" wall DOM tubes
- Provides a major increase in strength over stock housing.
- Provides a major increase in strength over stock housing.
- Large Bearing Large Bolt Billet Housing Ends
- Pre-welded Leaf Spring Mounts
- Drilled & Taped Breather Hole accepts Stock Breather Bolt
If switching from a small bearing housing, you will need to add the available 1/2" T-bolts. Third member studs are also available. If you have them, you can use your old studs and T-bolts (large bearing) from your existing housing.
This early Bronco rear axle housing comes in bare steel.
California residents: Proposition 65 Warning
Q&A
Have a question? Click Here to submit your question.
Asked by Shaun, May 28, 2024 15:23
Q: Can I use the drum brakes and backing plates from my 67 small bearing 9"
⮞ 1 Answer
Answered by ☆ sales - May 28, 2024 15:24
A: No, not without modification to the backing plate at the very least. Also, you would need to have large bearing axles that match the brakes bearing offset. Usually you cannot mix and match.
Asked by Joel David Rodriguez, May 28, 2024 15:22
Q: Since the Axle tubes are a smaller 3", does that mean we need to use smaller diameter U bolts when installing the leaf springs? I noticed your heavy duty Ubolt set uses 3 1/4" wide U bolts
⮞ 1 Answer
Answered by ☆ sales - May 28, 2024 15:25
A: You do not need different u-bolts. When tightened, they will follow the contour of the tubing, and hold tight.
Asked by Domenic, May 28, 2024 15:22
Q: I recently purchased this housing. I will be building it for my bronco. I definitely use my rig, but I dont abuse it. Do you see any need to truss this housing? I will be running a Tru hi9 center section with 4.88 gears and a yukon grizzly locker with your 35 spline axles. I plan on running 37 inch tires.
⮞ 1 Answer
Answered by ☆ sales - May 28, 2024 15:25
A: You may not need it, but the added strength and rigidity may be nice. And... it looks cool.
Asked by RG, May 28, 2024 15:21
Q: Does this Super 9 Housing take the same Axles and Brakes as the Original 1977 Bronco housing? Thank you
⮞ 1 Answer
Answered by ☆ sales - May 28, 2024 15:25
A: Yes, either 66-75 axles and brakes or 76-77 axles and brakes, for large bearing with 1/2 retainer bolts.
Asked by Kim, May 28, 2024 15:21
Q: What's the flange bolt pattern, early big bearing 11" drum or late/Torino big bearing?
⮞ 1 Answer
Answered by ☆ sales - May 28, 2024 15:25
A: It is the Big Bearing 11" drum pattern for 1/2" retainer bolts. Not the Torino style with 3/8" retaining bolts.
Asked by FML, May 28, 2024 15:20
Q: Is this housing American made? Do you feel it is stronger than the '76/'77 housing?
⮞ 1 Answer
Answered by ☆ sales - May 28, 2024 15:26
A: The housings are made in America. It is better constructed and or stronger with .250 wall tube than a stock 77 housing.
Asked by tom, May 28, 2024 15:19
Q: i recently purchased this housing and want to know if the billet bolt ends will work with my tappered bearings on my 35 spline axles our do i need to replace the bearings on the axles. thanks
⮞ 1 Answer
Answered by ☆ sales - May 28, 2024 15:27
A: The tapered roller bearings have the same outside diameter as the standard large bearings.
Asked by Mark Womack, May 22, 2023
Q: Will the Explorer disc brake kit bolt up to these ends?
⮞ 1 Answer
Answered by ☆ sales - May 24, 2023
A: Normally the Explorer setup uses 3/8 retaining bolts. If your kit does, then no, not without re-drilling the backing plates. If your kit uses 1/2 retaining bolts, then we are not aware of any issue and it should work.
Asked by Domenic, October 6, 2021
Q: I recently purchased this housing. I will be building it for my bronco. I definitely use my rig, but I dont abuse it. Do you see any need to truss this housing? I will be running a Tru hi9 center section with 4.88 gears and a yukon grizzly locker with your 35 spline axles. I plan on running 37 inch tires.
⮞ 1 Answer
Answered by ☆ sales - October 8, 2021
A: You may not need it, but the added strength and rigidity may be nice. And... it looks cool.
Asked by JOEL DAVID RODRIGUEZ, October 3, 2021
Q: Since the Axle tubes are a smaller 3, does that mean we need to use smaller diameter U bolts when installing the leaf springs? I noticed your heavy duty Ubolt set uses 3 1/4 wide U bolts
⮞ 1 Answer
Answered by ☆ sales - October 6, 2021
A: You do not need different u-bolts. When tightened, they will follow the contour of the tubing, and hold tight.
Asked by RG, March 8, 2020
Q: Does this Super 9 Housing take the same Axles and Brakes as the Original 1977 Bronco housing?
Thank you
⮞ 1 Answer
Answered by ☆ sales - March 9, 2020
A: Yes, either 66-75 axles and brakes or 76-77 axles and brakes, for large bearing with 1/2 retainer bolts.
Asked by Kim, October 8, 2019
Q: What's the flange bolt pattern, early big bearing 11 drum or late/Torino big bearing?
⮞ 1 Answer
Answered by ☆ sales - October 9, 2019
A: It is the Big Bearing 11 drum pattern for 1/2 retainer bolts. Not the Torino style with 3/8 retaining bolts.
Asked by rod hester, July 31, 2019
Q: one of the pictures show that it has brake line tabs on the housing, is this correct. The one I received did not have these.
⮞ 1 Answer
Answered by ☆ sales - July 31, 2019
A: No, the new housing do not come with brake line securing tabs. The one in the picture had tabs welded to it before paint and install.
Asked by stephen, August 9, 2016
Q: Can this axle housing be ordered with anti-wrap leaf spring perches?
⮞ 1 Answer
Answered by ☆ sales - August 12, 2016
A: No, only with standard perches.
Asked by stephen, August 8, 2016
Q: Does this axle housing come with your anti-wrap leaf spring perches and how do you know what angle to weld them at for lifted rigs?
⮞ 1 Answer
Answered by ☆ sales - August 8, 2016
A: The housing does not come with the anti-wrap perches. The perches on it are welded on at an angle to help with lifted Broncos.
Asked by FML, June 24, 2016
Q: Is this housing American made? Do you feel it is stronger than the '76/'77 housing?
⮞ 1 Answer
Answered by ☆ sales - June 24, 2016
A: The housings are made in America. It is better constructed and or stronger with .250 wall tube than a stock 77 housing.
Asked by tom, January 26, 2016
Q: i recently purchased this housing and want to know if the billet bolt ends will work with my tappered bearings on my 35 spline axles our do i need to replace the bearings on the axles. thanks
⮞ 1 Answer
Answered by ☆ sales - January 27, 2016
A: The tapered roller bearings have the same outside diameter as the standard large bearings.
PRODUCT REVIEWS
Scott P
Reviewed 11/10/2020
Way stronger than my stock banjo housing, and probably marginally stronger than a 76-77 housing due to the 1/4" thick tubes. Mine didn't come notched as described though? Maybe a fluke, or time to change the product description. Notched or not wasn't a deal breaker for me, but it would easily get 5 stars if it only matched the description!
Note From WILD HORSES: Thanks for the heads up. Updates have been made sorry for any confusion.
Richard Ottomano
Reviewed 02/25/2018
Nice strong reinforcements
